Biography:
Hans Kosina received the Diplomingenieur degree in electrical engineering and PhD from the Technische Universität Wien in 1987 and 1992, respectively. He was with the Institute of Flexible Automation at the Technische Universität Wien for one year and then joined the Institute for Microelectronics, where he is currently an associate professor. He received the venia docendi in microelectronics in 1998. In the summer of 1993, he was a visiting scientist at Motorola Inc., Austin, Texas, and in the summer of 1999, a visiting scientist at Intel Corp., Santa Clara, California. Dr. Kosina served as a Technical Program Committee member in the IEEE International Workshop on Computational Electronics in 2003 and 2004 and was chairman of the ''11th International Workshop on Computational Electronics'' held in Vienna in May 2006. He has served as the Associate Editor of the IEEE Transactions on Computer-Aided Design of Circuits and Systems since January 2004. His current research interests include the device modeling of semiconductor devices, nanoelectronic devices, organic semiconductors and optoelectronic devices, the development of novel Monte Carlo algorithms for classical and quantum transport problems, and computer-aided engineering in ULSI-technology.

Physical Modeling of Advanced Semiconductor Devices

The development of the quantum transport simulator VSP has continued. In order to account for band non-parabolicity, an effective two-band k⋅p Hamiltonian has been implemented. The implementation of an eight-band Hamiltonian is in progress. These band models are used to predict the energy levels in multi-layer hetero-structures. Applications are quantum cascade lasers in the mid infra-red and the THz range.
The quantum transport model of VSP is based on the Non-Equilibrium Green's Function (NEGF) formalism. An effective adaptive energy integration scheme, capable of resolving very narrow resonances in the energy spectrum, enabled the numerical study of tunneling currents in gate stacks by means of the NEGF formalism. This approach rigorously treats both confined and free carriers in the channel and tunneling on a rigorous basis. The effect of scattering processes on level broadening has been approximated using an optical potential. The rigorous NEGF approach has been compared with the simpler quasi-bound-state tunneling model and the Tsu-Esaki model.
Carbon NanoTubes (CNTs) have a direct band gap, which can be tuned by the tube diameter. Therefore, CNTs are suitable candidates for opto-electronic devices, especially for Infra-Red (IR) applications, due to the relatively narrow band gap. IR photo detectors based on Carbon NanoTube Field-Effect Transistors (CNT-FETs) have been reported by many groups. To explore the physics and to improve the performance of such devices, self-consistent quantum mechanical simulations have been carried out. The numerical analysis is based on the NEFG formalism. The numerical models takes into account the tight-binding model for the band structure and self-energy terms for electron-photon and electron-phonon interaction.
A three-dimensional kinetic Monte Carlo simulator for transient phenomena in amorphous organic semiconductor devices has been further developed. The device physics of polymer-based opto-electronic applications is coined by the injection, propagation, extraction and accumulation of charges in layered assemblies of about 100 nm thin polymer films at field strengths of about 1 MV/cm. The software simulates the system's time evolution as a continuous time random walk. The simulator simultaneously follows the time-evolution of both the p- and the n-conductive band. All space charge and image-force effects have been regarded with full rigor. Disorder is modeled by Baessler's well-established Gaussian Disorder Model. The transition of electrons is governed by the classical Miller-Abrahams expression, which turned out to be adequate for bulk and hetero-junction simulations. However, many organic devices exhibit contact-dominated behavior. In this case the molecular structure of the bulk is less critical for a device's electrical characteristics than the chemical and morphologic structure of the bulk-electrode-interfaces. Since the Miller-Abrahams rate turned out to be inadequate for the simulation of charge injection and extraction in real space, it is currently replaced by a more advanced rate expression.


Band edge of a quantum cascade structure. The local density of states is obtained from a self-consistent, quantum ballistic transport calculation using VSP.
